Articul: PLO03108
This product is not available for purchase
We don't have the information when the item will be available again, so we suggest you to have a look at the offer of similar products available on our web site: MotherboardsAMD B450 Ultra Durable Motherboard with Realtek® GbE LAN with cFosSpeed, PCIe Gen3 x4 M.2, 7-colors RGB LED Strips Support, Anti-Sulfur Resistor, CEC 2019 ready
- Supports AMD Ryzen™ 5000 series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors
- Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
- HDMI, DVI-D Ports for Multiple Display
- Ultra-Fast PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support
- High Quality Audio Capacitors and Audio Noise Guard with LED Trace Path Lighting
- RGB Fusion supports RGB LED Strips in 7-Colors
- Realtek® Gigabit LAN with cFosSpeed Internet Accelerator Software
- Smart Fan 5 Features 5 Temperature Sensors and 2 Hybrid Fan Headers with FAN STOP
- APP Center Including EasyTune™ and Cloud Station™ Utilities
- CEC 2019 Ready, Save Power with a Simple Click
| Brand | Gigabyte |
| Procesorsko ležište (socket) | AMD® AM4 |
| Čipset | AMD® B450 |
| Maksimalna ukupna memorija | 128GB |
| Tip memorije | DDR4 |
| Memorijski slotovi | 4x DDR3 |
| Opis memorije | 4 x DDR4 DIMM sockets supporting up to 128 GB of system memory Dual channel memory architecture Support for DDR4 3600(O.C.)/3466(O.C.)/3200(O.C.)/2933/2667/2400/2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in |
| Grafika | Integrisani graficki procesor |
| PCI Express x16 slot | 2x PCI Express x16 slot 3.0 |
| PCI Express x1 slot | 1x PCI Express 3.0 |
| SATA priključci (ukupno) | 1 x M.2 Socket 3 |
| SATA priključci | 4x SATA III |
| Audio |
Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver. Support for S/PDIF Out |
| Ukupno USB priključaka | 8 |
| USB 2.0 priključci | 4 |
| USB 3.2 priključci | 4 x USB 3.1 Gen 1 ports |
| Back I/O Ports |
1 x PS/2 keyboard/mouse port 1 x DVI-D port 1 x HDMI port 4 x USB 3.1 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| Internal I/O Ports |
1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x CPU cooler LED strip/RGB LED strip header 1 x USB 3.1 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only) 1 x serial port header 1 x Clear CMOS jumper |
| HDMI priključci | 1x HDMI |
| DVI-D priključci | 1xDVI-D |
| PS2 | combined 1 komad keyboard (purple) mouse (green) |
| LAN | Realtek® GbE LAN chip (10/100/1000 Mbit) |
| RAID | RAID 0, RAID 1, RAID 10 |
| Format | microATX, M-ATX |
| Garancija | 36 mjeseci |
