Garancija:
36 months (3 years)
Brand:
Gigabyte
Procesorsko ležište (socket):
Intel® 1851
Čipset:
Intel ® B860
Maksimalna ukupna memorija:
256GB
Tip memorije:
DDR5
Memorijski slotovi:
4xDDR5
Opis memorije:
9066(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 5600 MT/s
Grafika:
Integrisani graficki procesor
PCI Express x16 slot:
1x PCI Express 5.0 (x16 mode)
PCI Express x1 slot:
2x PCI Express 3.0
SATA priključci:
4x SATA III, 2x M.2
Audio:
Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Back I/O Ports:
3 x USB 2.0/1.1 ports
1 x PS/2 keyboard/mouse port
1 x DisplayPort*
1 x HDMI port*
3 x USB 3.2 Gen 1 ports
1 x RJ-45 port
3 x audio jacks
Internal I/O Ports:
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x CPU fan/water cooling pump header
1 x system fan header
1 x system fan/water cooling pump header
2 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
2 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x serial port header
1 x Clear CMOS jumper
LAN:
Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
Žična mreža (LAN):
10/100/1.000Mbps (Gigabit ethernet)
RAID:
RAID 0, RAID 1, RAID 5, RAID 10
Format:
microATX
Ostalo:
Micro ATX Form Factor; 24.4cm x 24.4cm
Key Features
- Supports Intel® Core™ Ultra processors (Series 2)
- Hybrid 4+1+2 phases VRM solution
- D5 Bionic Corsa for Infinite Memory Performance
- AI Perfdrive : Provides optimal and customized BIOS preset profile for users
- EZ-Latch : PCIe x16 Slot with Quick Release Design
- Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
- Next Generation Storage : 2*PCIe 4.0 x4 M.2 Connectors
- Fast Networking : GbE LAN
- Extended Connectivity : DisplayPort, HDMI
